Core Module Vertical High Speed VFFS Salt Packaging Machine
Designed for 50 g to 2 kg pouches with cup or multihead weigher dosing Supports pillow flat bottom and stand up formats Frames and contact parts can be specified for corrosion resistance to handle salty environments.
Illustration Vertical form fill seal machine with quick changeover
- Continuous or intermittent motion selected by speed and film type
- HMI recipe management for rapid weight and format changes
- 304 or 316L contact parts optional sealed electrical enclosures
Products and Pack Ranges
- Products sea salt rock salt refined salt iodized salt low sodium salt blended seasoning salt
- Sizes 50 g to 2 kg pouches and 5 kg to 25 kg medium heavy bags
- Bag types pillow flat bottom side seal stand up open mouth pre made PE or laminate
Core Module Open Mouth Automatic Bagging System
For 5 kg to 25 kg formats with automatic bag pick dosing bag mouth shaping de aeration and sealing Compatible with paper plastic and PE heat seal materials Can be linked with palletizing for a complete end of line.
- Fast change between multiple bag sizes
- Heat sealing or stitching with neat bag mouth shaping
- Linked dust extraction and weighing buffer for clean operation
Illustration Open mouth bagging system for 5 kg to 25 kg salt
Standard Process and Control Points
- Pre treatment salt screening and decontamination optional de ironing
- Dosing by cup multihead weigher or screw based on granularity and accuracy
- Filling small pouches on VFFS medium heavy bags on open mouth bagger
- Sealing pouches by heat or ultrasonic heavy bags by heat or stitching with folded edges
- Inline coding batch and date labels or thermal transfer
- Inspection dynamic checkweighing and metal detection with combined rejection
- Case packing and palletizing with stretch wrap or over bag for moisture protection
- Data and traceability batch barcode and records connectable to MES or WMS
Quality Control and Traceability
Combine checkweighing and metal detection to intercept underweight overweight and foreign bodies and bind results to batch data for traceable reports.
Illustration Compact combination unit for weight and metal inspection
- Dynamic weighing across common net weight ranges
- Multi frequency metal detection for stainless and non ferrous
- Dual rejects to separate weight failures and foreign body failures
Capacity and Configuration
- High speed small pouch line 60 to 120 bags per minute with continuous VFFS and multihead weighers
- Medium heavy bag line 10 to 20 bags per minute with open mouth or FFS bagging
- Unified HMI recipes support fast change from 50 g to 25 kg
Hygiene and Corrosion Resistance
- 304 or 316L contact materials sealed bearings and enclosures for salty environments
- Dust hoods at drop and stitching points connected to a central duct
- Tool free hopper and guide removal optional IP65 to IP69K equipment
Implementation and Services
- Line layout and interface lists with drawings and I O tables
- FAT and SAT operator training spare parts and maintenance plan
- Remote support periodic inspections and report templates
Image Credits and Licensing
These are real equipment illustrations Please verify licensing for commercial use or replace with owned assets
- Vertical VFFS packaging machine image IMA Ilapak official page
- Open mouth bagging system image Concetti official page
- Checkweigher and metal detection combination image Mettler Toledo official page
